This poster bundle includes 7 unique, high quality, professionally printed posters. Each poster focuses on the refrigeration cycle for various types of HVAC/R systems and includes all major refrigerant components within the systems. The 7 specific posters included in this bundle:
- The Basic Refrigeration Cycle
- The Refrigeration Cycle of an Air Conditioner
- Heat Pump Refrigeration Cycle: Air Conditioning
- Heat Pump Refrigeration Cycle: Heating
- Ductless Mini-Split Refrigeration Cycle: Air Conditioning
- Ductless Mini-Split Refrigeration Cycle: Heating
- Walk-In Box Refrigeration Cycle
Poster bundles are available in two sizes.
Select either 23" x 35" or 12" x 18"
